Automatic Tumble Belt Blast Machine

This automatic type tumble belt blast machine is suited for batch processing of small and medium sized parts that is relatively heavy, complex-shaped parts which would be hard to handle in a traditional blasting cabinet.
  • KF-A40


Automatic Tumble Belt Blast Machine

Parts tumble on a thick, perforated rubber belt, a group of blast guns uniformly blast medias to all exposed surfaces to deliver a consistent finish automatically. Our automatic blasting system can be designed to address all process constraints and for optimal results and productivity.

tumble belt blasting machine

tumble belt blast machine

Tumble Belt Sand Blast Machine Features

  • Long life, wear-resistant rubber belt with a loading capacity of 100kgs.

  • Each blast gun is individually controlled thus to select single gun or multi-gun working according to the quanlity of parts.

  • Blast media is continuously separated from dust by a cyclone device, returning only pure medias in good shape back to the blast nozzles for optimal results.

  • Configured a pulse filter cartridge for dust removal system, features high removal efficiency.\

  • Easy-to-use electric control to adjust blasting pressures, belt tumbling speed, and blasting cycle time, etc.

  • The blast guns quanity, rubber belt size, chamber size all can be tailored to the customers specifications


Tumble Belt Blast Machine Specifcations


Working cabinet:

L600*W500*H500 (mm)

Cabinet outsize:

L800*W650*H2720 (mm)

Dust collector dimensions:



0.3-0.5 T/H

Load capacity:


Rolling motor power:


Dust collection motor power:


Automatic blasting gun:

4pcs Aluminium alloy blasting guns, with 4pcs boron carbide nozzles, dia 8mm.


380V 50HZ
