KF-K1-TC Laboratory Powder Coating Cup Gun

Lab powder coating gun system
Easy electric and pneumatic parameter control
Budget-saving and reliable powder coating solution
Powder gun pare parts always available
1 year warranty time
  • KF-K1-TC

  • Kafan

  • Pwder Coating Cup Gun


Laboratory Powder Coating Cup Gun

Laboratory powder coating cup gun can carry 1 lbs powders that exactly meets very small series application such as sample parts testing, powder testing, hobby use. The K1 series control system features easy and efficiency, whether for beginners or experienced users, air control and powder flow control by pressure valves simplify operation, digital kv adjustment ensures precise electrostatic charge on powder particles. You can order multipe powder cups for frequent color change.

powder coating cup gun

KF-K1 Powder Coating Gun Intelligent Controller Features

  • Three one-button application programs pre-set for beginners, including flat parts coating program, corner coating program, re-coating program.

  • 0-100kv voltage adjustable by digital, help you easily find the optimal data for different applications

  • Easy regulation of pneumatic parameters by mechanical valves, reliable and durable.

  • Perfect coating results for whether flat shape parts or complex shape parts, increase working efficiency, reduce powder cost.

   K1 powder gun control

Manual Powder Spray Gun

  • Unique ergonomic design, lightweight to reduce operator's fatigue

  • 100kv built-in voltage cascade for high transfer efficeincy and reduce powder waste

  • Quality material and non-stick of powders, fast cleaning during color change

  • Round and flat nozzles are suitable for most common work parts, nozzles with an extension is more easy to penetration corners, and for inside coating of narrow areas.

   manual powder coating gun

KF-K1 Powder Coating Gun Parts

  • Including nozzles, air tubes, gun calble, grounded wire, air moisture separator etc. All the parts for the KF-K1 powder coating machine are in optimal performance.

  • Comes with full array of nozzle assortment to optimize your spraying effect, including flat nozzle, round spray nozzles with different size deflectors, and extension nozzles.

  powder coating gun parts


Powder Coating Gun Cup

  • Size: D10xH10cm, Capacity: 1 pounds powders, suitable for lab testing use or mini scale jobs.

  • The powder cup directly connects to the spray gun, without powder hose and injector.

  • Made of non-stick materials, can be dismounted into parts, which is easy to clean during color change

  • The fluidizng powder cup prevents the powder block, delivers smooth powder conveying.

  • It is also well sealed that keeps the powders from contaminants and damp.

   mini powder coating hopper

KF-K1-TH Powder Coating Spray Gun Technical Data

Model KF-K1-TH Portable Type
Power range   220/110V 1 Phase (customized as local)
Frequency   50HZ
Temperature range in use -10 ℃+50 ℃
Powder Gun
Gun weight:    … 500G
Rated output voltage 24VDC
Maximum output current 180Ua(max)
Maximum output voltage 0-100KV (  adjustable)
Maximum powder injection : 600g/min
Polarity negative (-)
Pneumatic data
Maximum input-air pressure 10kg/cm
Optimum input-air pressure 6kg/cm
Minimum input-air pressure 4kg/cm
Maximum water vapor content or compressed air 1.4g/N m3
Maximum oil vapor content of compressed air 0.1ppm
Maximum compressed-air consumption 13.2 m3/h

Why choose kafan powder coating gun system?

Based on Kafan 10 years design and manufacture technology, and over 100 exported countries, kafan will meet all of your powder coating demands, whether single color application or frequent color change, whether for big production or lab use.

Kafan powder coating spray units delivers high performance and efficiency for both regular shape parts and complex shape parts. Save cost and improve quality.

KF-K1-TC Laboratory Powder Coating Cup Gun Operation Guide

1. Kafan Pre-sales Service

Inquiry on the website or directly contact with our sales, they are well speaking in English, Spanish, German, Russian, and 24hour online for any of your questions. Our sales is knowledgeable for powder coating machines and applications. We have professional techinical team, productions, quality control team, management and finance team, etc.

Kafan powder coating gun

2. Kafan On-sales Service

Before orders, we need get clear of below questions

Q1: Are you a distributor or powder coating users?

If you are a user, we need know your actual condition to offer solution, replace your old machines or just begin to build a powder coating plant. If you are a distributor, we have preferential strategy to help you sell our powder guns.

Q2: What metal product do you coat?

Our powder coating equipment is applicable for coating every kinds of metal parts, whether flat panel or complex shapes.

Q3: Do you have many powder colors need to be frequently changed?

If one or two powder colors, choose the hopper type powder coating machine, if many powder colors, choose the box feed powder gun system, fast and convenient for color change.

Q4: What is the required production capacity?

Manual powder coating equipment for small and normal production. Automatic powder coating system for large production (including auto powder gun equipment, reciprocator, automatic powder coating booth, etc)

Q5: What is your local voltage?

Before production, we must confirm your voltage, we can customized based on your local, 110V/220V/380V/410V, etc.

Powder Coating Equipment Production

Design & Drawing (for non-standard products) - Material Preparing(CNC punching, bending, welding) - Preliminary Assembly - Surface Coating - Complete Assembling - Electricity Connection - Testing


Packing & Delivery

Order of powder coating gun and parts, wooden case for sea shipping, cartons for international express, each machine is wrapped with film first to prevent scratch, each package is filled with foam to eliminate damage.

For powder spray booth or large quantities orders, if reach to a certain dimension, we can ship you by a full 20’ or 40’ container. That is much safer.

powder coating equipment packing  Packing  delivery

3. Kafan After Sale Service

  • Each powder coating equipment is delivered with a manual to guide you how to Install & operation, any doubts contact with our sales, or watch our teaching videos.

  • One year warranty for any quality problem, free replace of main parts, PCB, cascade, gun cable(not includes wearing parts.

  • We will call back or email back to ask your satisfactory of using our machine, and anything if you need our help.

  • Powder coating equipment daily maintenance, technical upgrading, sale promotion will be offered to you.

  • Build warehouse for quick wearing parts and replacements, such as spray nozzles, insert sleeves, gun shells, injectors, powder hose, etc.
